12 Display & Cine Review
Operator’s Manual 12 - 7
• When a saving is completed, a thumbnail is showed in the Thumbnail area.
12.6.2 Frozen image storage
In frozen mode, tap [Pro Capture] / [Retro Capture] on the touch screen or press the user-defined
key (The key has already been assigned the function as “Save Clip retrospective or prospective”).
After the cine is successfully saved, there is a thumbnail displayed on the screen.
12.7 Setting Cine Length
The system ends up saving if the cine length goes beyond the maximum value.
12.7.1 Live capture
Retrospective Cine Length
Prospective cine duration: set the time that the user taps [Prospective] as the start time. The system
proceeds saving the cine.
• With the ECG disabled: tap [Cine] tab, and use [Time (Pro)] to adjust it.
• With the ECG enabled: tap [Cine] tab. Tap [Saving type (Post)] to choose the type of the
saving time and the cardiac cycles. Use [Time (Post)] or [Cycle (Post)] to adjust it.
Prospective Cine Length
Retrospective cine duration: set the time that user taps [Retro] when playing the first frame of the
image. It also refers to saving the cine or cycles retrospectively.
• With the ECG disabled: tap [Cine] tab, and use [Time (Retro)] to adjust it.
• With the ECG enabled: tap [Cine] tab. Tap [Saving type (Retro)] to choose the type of the
saving time and the cardiac cycles. Use [Time (Retro)] or [Cycle (Retro)] to adjust it.
12.7.2 Freeze storage setting
The first frame of the image starts when the user presses <Freeze> at the first time. The system
saves the cine in the auto review scope retrospectively.
Press <Freeze> to freeze the image. Use [Time (Retro)] to set the cine time of retrospective saving
in frozen status under Cine page, or mark the start frame in the auto review scope to set the cine
time of retrospective saving in frozen status.
It is only available to save the cine retrospectively in the frozen status.
