Mindray MX7 User Manual

17 - 2 Operator’s Manual
17 DVR Recording
Perform the following procedure:
1. Click to open the dialog box, and click [Local Video Management] to enter the managing
dialog box.
Click [Rename] to rename the video file.
2. Select the destination and the target file, click [Send] to send the file to the selected path.
During sending progress, the icon displays as .
17.3 DVR Video Replay
You can replay the video and audio record.
17.3.1 Replay on PC
Connect the USB disk or optical disk with the file to the PC, open the file directly.
17.3.2 Replay on the ultrasound system
Perform the following procedure:
1. Click to open the dialog box and select desired playing type: Hard disk/USB/CDROM.
2. Click [Play] to open the dialog box.
3. Select the path and name for the file and then click [OK] to replay the file, or double-click the
file name directly.

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
