4 Setup
Operator’s Manual 4 - 5
4.1.4 Application
Set the measurement ruler, measurement setting, follicle method, left ventricular setting, comment
setting and so on.
PARAMETER Steer To set the steer mode in B + Color + PW/CW
imaging mode.
• C&(PW/CW): select to adjust the sample
volume in color mode and sample line in
PW or CW mode together.
• C/(PW/CW): select to adjust the sample
volume in color mode and sample line in
PW or CW mode separately.
Auto Invert The spectrum can automatically invert when
the color flow is steered to a certain angle, thus
accommodating the operator’s wish to
distinguish the flow direction.
iScape Ruler Display To set whether to display the iScape ruler in
iScape imaging mode.
B+Color Refresh with PW/
CW Sampling Line
Movement
To set whether to turn on the function that
when moving PW/CW sampling line, B+Color
image is activated under B+Color+PW/CW
mode.
Uninterruptible image saving
when reprocessing
parameters are changed
Adjusting reprocessing parameters will not
interrupt image/cine saving.
Color And PW/CW
Synchronize Invert
Adjust preprocessing parameter, refresh 2D/
M/Doppler cine.
Color And PW/CW
Synchronize Invert
To set whether to invert Color Map and PW/
CW spectrum synchronously
Display Transducer SN To set whether to display the transducer SN.
B+Color+PW UnFreeze
keeping PW
To set whether to retain PW images when
unfrozen under B+Color+PW mode.
TOUCH
SCREEN
Touchpad Layout Design To set the layout style of the touch screen.
TISSURE
TRACKING QA
Segment Model To set the cardiac segment model: 16 or 17.
Type Item Description
