EN-39
5.2.2. Configure the Output
6. Use or to move to the required Out.x and press key.
7. Set the parameters below using or , then press key to confirm and move to
the next menu/sub menu.
Name
Value
Description
O.Act
Direction of operation OUT1
0
Direct / normally open
1
Inverse / normally closed
Lim.1
Signal limit 1 (Result of comparison of limit 1 values
with actual weight
0
Not active
1
Active
Lim.2
Signal limit 2 (Result of comparison of limit 2 values
with actual weight)
0
Not active
1
Active
Lim.3
Signal limit 3 (Result of comparison of limit 3
values with actual weight)
0
Not active
1
Active
FAi.1
Signal INP fail
0
Not active
1
Active
8. After configuring the required outputs, use or to move to End and press key.
5.2.3. Setting Values for Limit Processing
9. Press the key for more than 3 sec and go to Inst
10. Use or to go to PArA and press key
11. Use or and move to Lim
12. Set the limit values based on the output requirement using or and confirm with
the key
Limits
Range
Description
L.1
-1999...9999
Display value lower limit (L.1< -1999 then L.1 is off )
H.1
-1999...9999
Display value upper limit (L.1< -1999 then H.1 is off )
HYS.1
0...9999
Hysteresis for limit value 1
L.2
-1999...9999
Display value lower limit (L.2< -1999 then L.1 is off )
H.2
-1999...9999
Display value upper limit (L.2< -1999 then H.1 is off )
HYS.2
0...9999
Hysteresis for limit value 2
L.3
-1999...9999
Display value lower limit (L.3< -1999 then L.1 is off )
H.3
-1999...9999
Display value upper limit (L.3< -1999 then H.1 is off )
HYS.3
0...9999
Hysteresis for limit value 3
Limit value processing is as shown below.
