Minebea Intec MP 26 User Manual

MP 26 Transmitter Installation and Calibration Manual
Minebea Intec
EN-45
7. Technical Data
7.1. Inputs
7.1.1. Input M
Resolution:
>19 Bit
Decimal point:
0 to 3 decimals
Digital input filter:
adjustable 0.0 to 999.9 s
Scanning cycle:
50 ms
Linearization:
31 Segments, adaptable with Engineering
tool MP 26
Measurement value correction:
2-point
Limiting frequency
1.7 Hz
Measurement value correction:
Sensor break, short circuit and polarity
Connection technology:
4-wire bridge
6-wire bridge (Sense line)
Input range
Span start, span end
any, within measuring range
Scaling
any, -1999 to 9999
Measurement span
Slope/sensitivity
0.5 mV/V
1 mV/V
2 mV/V
4 mV/V
7.1.2. Digital Input DI1
Operation as Contact input
Connection of a potential-free contact that is suitable for switching ‘dry’ circuits.
Switched voltage:
5 V
Current:
0.5 mA
Operation as Control input
Configurable as direct or inverse switch or push button!
Functions:
Operation disabling, reset of stored alarms
and the min/max indicator (slave pointer),
the integrator, enabling the tare
function,Sample&Hold amplifier function,
Cal-Test , and zero setting.
