7.2. Outputs
7.2.1. Relay Outputs OUT1, OUT2
Contact type:
2 normally open with common contact
connection
Max. contact rating:
500 VA, max. 250 V, max. 2 A at 48...62 Hz,
ohmic load
Min. contact rating:
6 V, 1 mA DC
Swithing cycles (electrical):
for I = 1 A/2 A:
>
800,000/500,000 (at~250V
(ohmic load))
Note:
If the relays OUT1, 2 and 3 are used to operate external contactors, these must be fitted
with RC snubber circuits to manufacturer specifications to prevent excessive voltage peaks
at switch-off.
7.2.2. OUT3 as Universal Output
Parallel current/voltage output with common ‘minus’ terminal (combined use only in
galvanically isolated circuits).
Freely scalable resolution:
14 Bit
Dynamic response (step change of input
signal) T90:
Output follows the input within 300 ms
Tracking error I/U:
<
2 %
Residual ripple:
<+1%
(rel. to range end)
0...130 kHz
Current output
0/4...20 mA, configurable, short-circuit
proof.
Control range:
-0.5…23 mA
Load:
<
600
O
Load effect:
<0.02 %
Resolution:
<1.5 µA
Error:
<
0.1 %
Voltage output
0/2...10V, configurable, not permanently
short-circuit proof
Control range:
0.15...11.5 V
Load:
>
2 k
O
Load effect:
<0.06 %
Resolution:
<
0.75 mV
Error:
<0.1%
Additional error when using simultaneously
the current output
<
+0.09%
