MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 19
Elevator-Recall (Restriction) is available with single and multiple entrances and is programmed accordingly.
1. SINGLE ENTRANCE - ELEVATOR-RECALL
At the ADC controller the relays are programmed to activate in association with a specific Resident/Tenant Code.
Elevator-Recall (Restriction) relays are available as the relays in the relay cabinet designated as sixteen.
For example: A single entrance system consists of an ADC Controller and one relay cabinet. This relay cabinet is
used as Elevator-Recall (Restriction) relays (the motherboard is jumpered as shown in Figure 11A). Therefore it is
necessary to associate all residents on the same floor with one Elevator-Recall (Restriction) relay. Sample
programming at the ADC Controller would be as such:
Resident/Tenant Code Elevator-Recall Relay
1201 12
1202 12
1203 12
1301 13
Looking at the information above the first two digits of the Resident/Tenant Code represents the resident’s floor and
the relay. Therefore all residents on the twelfth floor activate the same Elevator-Recall (Restriction) relay (relay
number 12 on the first relay card).
2. MULTIPLE ENTRANCES - ELEVATOR RECALL
For systems with more than one entrance, each ADC Controller must be programmed for the Elevator-Recall
(Restriction) application separately. Each ADC Controller requires its own set of relays.
EXAMPLE:
When a Resident/Tenant Code of “1205" is entered on the ADC keypad at the entrance, then the Elevator Recall
(Restriction) relay number 12 (twelfth relay on card number 1) will be activated. If the Resident/Code is 1822, then
relay number 18 (sixth relay on card number 2) will be activated. The relay numbering scheme is tabled below.
9512E ELEVATOR-RECALL RELAY CARDS IN
A 9508 RELAY CABINET
Relay Card Number 1 (Relay number 1 to 12)
Relay Card Number 2 (Relay number 13 to 24)
Relay Card Number 3 (Relay number 25 to 36)
Relay Card Number 4 (Relay number 37 to 48)
Relay Card Number 5 (Relay number 49 to 60)
Relay Card Number 6 (Relay number 61 to 72)
Relay Card Number 7 (Relay number 73 to 84)
Relay Card Number 8 (Relay number 85 to 95)
LAST RELAY NOT USED
NOTE: FIRST TWO DIGITS OF THE RESIDENT/TENANT CODE REPRESENTS THE ELEVATOR- RECALL
RELAY NUMBER.
WHEN USING ELEVATOR-RECALL (RESTRICTION) IT IS NECESSARY TO USE A SEPARATE
TIMER FOR EACH OF THE FLOOR RELAYS.
