Audio Amplifier Wiring
96
Figure 66: QAA-4CLAS Class A Conv
erter For QAA-5230S-70/25 Amplifier
O4 +
O4 +
R4 +
R4 -
O4 -
O3 +
R3 +
R3 -
O3 -
O2 +
R2 +
R2 -
O2 -
O1 +
R1 +
R1 -
O1 -
O1 -
J1
J2
J3
J4
SPEAKER
SPEAKER
SPEAKER
SPEAKER
QAA-5230S-70/25 AMPLIFIER
QAA-4CLAS
REMOV
ABLE TERMINAL
BLOCK
QAA-4CLAS
TERMINAL
BLOCK
TO WIRE QAA-4CLAS, REMOVE
TERMINAL FROM
QAA-5230S-70/25
AMPLIFIER, CONNECT
TO QAA-
4CLAS
AND SCREW DOWN. WIRE THE FOUR CLASS
A
CIRCUITS T
O THE 16
TERMINALS
AS SHOWN IN
DIAGRAM A
T
RIGHT
.
ALL
CIRCUITS
ARE POWER LIMITED.
15 W
A
TTS MAX. PER ZONE.
NOTES:
1.
2.
3.
99
101
