Appendix A: Specifications
126
ULI/ULC Integrated Fire Alarm and Audio Panel Specifications
Overall
PS-2040 Power Supply
• 0 to 49 degrees Celsius, 0 to 93 + or - 2% RH (non-condensing) operating range
• Power input: 120 VAC, 60Hz, 12A or 240 VAC, 50Hz, 6A (primary), Not Power-limited
• Power supply ratings: 8.5A (x2), 18.85-0-18.85V (secondary)
13A, 29V (secondary)
Model QPS-5000N & QBC-5000N Power Supply & Charger
• Primary input 120 VAC, 60Hz, or 240 VAC, 50HZ, 12Amp, Not Power-limited
• Charging for up to 65 AH of 24 VDC batteries
• Float Type Charger
Model FNC-2000 Fire Network Controller Module
• Current consumption: standby: 190mA
alarm: 190mA
Model ANC-5000 Audio Network Controller Module
• Current consumption: standby: 255mA
alarm: 265mA
Model TNC-5000 Telephone Network Controller Module
• Current consumption: standby: 195mA
alarm: 215mA
Model FOM-2000-SP Fiber Optics Module
• Current consumption: standby: 15mA
alarm: 15mA
Model QAA-5160-70/25 Amplifier with one 70V or 25V, 60 Watt Zone
• 70.7Vrms or 25V constant voltage output
• One fully supervised Class "A" or "B" speaker Zone
• 60 watts per zone
• Freq. Response: ULI bandwidth from 800 to 2800 Hz
• Harmonic distortion less than 2.5% at 1 KHz
• Current consumption: standby: 55mA
alarm: 350mA, plus 65mA/Watt Speaker Power
Model QAA-5230-70/25 Amplifier with two 70V or 25V, 30 Watt Zones
• 70.7Vrms or 25V constant voltage output
• Two fully supervised Class "A" or "B" speaker zones
• 30 watts per zone
• Freq. Response: ULI bandwidth from 800 to 2800 Hz
• Harmonic Distortion less than 2.5% at 1 KHz
• Current Consumption: standby: 55mA
alarm: 350mA, plus 65mA/Watt Speaker Power
Note: All circuits are power limited, unless specified otherwise.
