Mircom flexnet User Manual

FleX-Net
TM
Installation and Operation Manual
125
FOM-2000-SP Fiber Optic Module FNC-2000 Network Controller Module
Current Consumption: standby: 15 mA
alarm: 15 mA
Current Consumption: standby: 190 mA
alarm: 190 mA
ANC-5000 Audio Controller Module RAXN-LCDG Annunciator
Current Consumption: standby: 255 mA
alarm: 265 mA
24V DC nominal.
Standby: 117 mA Max., All LED's "On": 150 mA Max
TNC-5000 Telephone Controller Module RAXN-LCD Annunciator
Current Consumption: standby: 195 mA
alarm: 215 mA
24V DC nominal, range of 20 to 39V DC.
Standby: 100 mA Max., All LED's "On": 150 mA Max
Fan Damper Display Module (FDX-008/KI) Adder Annunciator Module RAX-1048/TZ/TZDS
24V DC nominal, range of 20 to 39V DC.
Current Consumption: standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
48 Display Points (TZ version has 48 extra trouble display points).
Current Consumption: standby: 139 mA
alarm: 1 zone LED active: 26 mA
2 zone LEDs active: 30 mA
3 zone LEDs active: 35 mA
4 zone LEDs active: 39 mA
48 zone LEDs active: 262 mA
Selection Control Panel (FDS-008)
24V DC nominal.
Current Consumption: standby: 24mA Max.
alarm (all LEDs ON): 112mA Max.
Digital Communicator Module (UDACT-300A) Programmable Input Switches Module (IPS-2424/DS)
Transmit alarm, supervisory, and trouble to a central
monitoring station.
Current Consumption: standby: 45 mA
alarm: 120 mA
Current Consumption: standby: 10/5 mA
alarm (one zone active): 15/22 mA
DSPL-420 AND DSPL-2440 Displays
Current Consumption: standby: 25mA and 35mA
alarm: 25mA and 30mA
Compliance
System Model: FleX-Net
TM
Series Fire Alarm/Alarm Control Panels FX-2003-12N/DS,
FX-2009-12N/DS, FX-2017-12N/DS, FX-2000ND and FX-2000MNS.
System Type: Local, auxiliary (using PR-300), remote protected premise station (using PR-300 or
UDACT-300A), central station protected premises (using UDACT-300A).
Type of Service: A, M, WF, SS (with PR-300 or UDACT-300A)
Type of Signalling: Non-coded
Applicable Standards: NFPA 70 and 72, UL-864 Rev.9, UL 2572, ULC S-524, ULC S-527-99
