QMT-5302NV Vertical Master Telephone
118
QMT-5302NV Vertical Master Telephone
The QMT-5302NV Vertical Master Telephone Module fits into the new BBX-FXMNS Enclosure. The master
telephone is mounted to the inside chassis and field wiring is on the BBX-FXMNS backbox. CONNECTIONS AND
TERMINAL WIRING ARE THE SAME AS THE QMT-5302N, WIRE AS SHOWN IN THE FOLLOWING
INSTRUCTIONS FOR QMT-5302N MASTER FIREFIGHTERS’ TELEPHONE.
Figure 84: QMT-5302NV Master Firefighters’ Telephone
CALL CONTROL
ACTIVE
CALL CONTROL
DESELECT ALL
TROUBLE
INCOMING CALL
