QMT-5302N Master Firefighters’ Telephone
The QMT-5302N mounts into the BB-5008 and BB-5014. QMT-5302N Network Master Firefighters' Telephone
Control Module is used in conjunction with the FleX-Net
TM
Fire Alarm system at the CACF Node. Slide-in labels
(NP-6657) are supplied with the Master Telephone. Place labels as shown in Figure 85. The QAZT-5302/DS
Telephone Selector panels are used for selecting telephone zones (up to 24 zones per selector panel) and include
blank labels for labelling the telephone zones.
Figure 85: QMT-5302N Master Firefighters’ Telephone
CALL CONTROL
ACTIVE
CALL CONTROL
DESELECT ALL
TROUBLE INCOMING CALL
