FleXNetTM Mass Notification System (BBX-FXMNS) Enclosure

Figure 53: Mounting Vertical Microphone and Telephone Modules in the BBX-FXMNS

Door Hinge

Door Hinges

Door Hinge

Modules are

mounted from the

backside of the

middle door using

the screws

provided

Back side of BBX-FXMNS inner door
