FX-2000 Series Installation and Operation Manual
7
Figure 2: BBX-1072A Flush or Surface Enclosure Installation and Dimensions
Note: Leave bottom of box conduit free for batteries.
Material: Cold rolled steel
16GA (0.059”) thick for backbox
14GA (0.075”) thick for door
Finish: Painted except for hinges
