FX-2000 Series Installation and Operation Manual
59
Appendix A: Specifications
Main Fire Alarm Chassis (FX-2003-6) Main Fire Alarm Chassis (FX-2017[S]-12A)
General
One Analog Loop capable of monitoring 99 Sensors and 99
Modules.
Power limited: 22 VDC, 400 mA max, max loop resistance
40 4 Style Y or Z (Class B or A) Indicating Circuits;
configurable as strobes or audibles. Terminals are labelled
"IND".
Power limited: 24 VDC unfiltered, 1.7 A @ 49°C per circuit
Displays (incl LCD) and Controls for all Common
Functions, and 16 Zone Displays.
Optional PR-300 City Tie Module.
Aux. Power Supply (for Remote Annunciators). Terminals
are labelled "AUX PWR".
Power limited: 24 VDC unfiltered, 1.7 A @ 49°C
Resettable 4-Wire Smoke Supplies. Terminals are labelled
"4-WIRE".
Power limited: 22 VDC, 400 mA max., 5mV ripple
One RS-485 Connection for Remote Annunciators or
interface to Audio Systems. Terminals are labelled "RS485".
Power Limited to 300 mA.
Auxiliary relays: (resistive loads)
Must be connected to a Listed Power Limited Source of
Supply. Terminals are labelled "ALARM, TROUBLE, SUPV".
Common Alarm: Form C, 1 Amp, 28 VDC
Common Supv: Form C, 1 Amp, 28 VDC
Common Trouble: Form C, 1 Amp, 28 VDC
Micro-controller based design.
Fully Configurable with PC software.
Full walk test function.
Electrical Ratings
AC Line Voltage: 120V 60Hz / 240V, 50Hz
2 Amps / 1 Amp (primary)
Power Supply ratings: 6 Amps. max. (secondary)
For Indicating Circuits: 24VDC unfiltered
5 Amps. max.
Battery: 24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability: 10-24 AH batteries
Current Consumption: standby: 230 mA
alarm: 380 mA
Same as FX-2003-12 except:
Larger Chassis incl. capacity for 48 zone displays, and 48
configurable displays and controls.
Single Intelligent Analog Loop Module (ALC-198S)
One Analog Loop capable of monitoring 99 Sensors and 99
Modules.
Power limited: 22 VDC, 400 mA max,
max loop resistance 40
Current Consumption: standby: 50 mA
alarm: 60 mA
Dual Intelligent Analog Loop Module (ALC-396S)
Two Analog Loops capable of monitoring 198 Sensors and
198 Modules.
Power limited: 22 VDC, 400 mA max,
max loop resistance 40
Current Consumption: standby: 50 mA
alarm: 60 mA
Loop Controller Module (ALC-H16)
Provides connection for adding up to 16 FA-1000 style adders
DM-1008A, SGM-1004A and RM-1008A.
Current Consumption: standby: 35 mA
alarm: 50 mA
Signal Adder Module (SGM-1004A)
Four Class B or A (Style Y or Z) indicating circuits;
configurable as strobes or audibles. Terminals are labelled
"IND".
Power Limited: 24 VDC unfiltered
max. 1.7 amps @ 49C per circuit
Current Consumption: standby: 60 mA
alarm: 258 mA
Relay Adder Module (RM-1008A) (resistive loads)
Must be connected to a listed power limited source of supply.
Terminals are labelled "RLY".
Eight fully configurable Form C indicating.
Form C, 1 amp., 28 VDC (resistive loads)
Current Consumption: standby: 25 mA
alarm: 150 mA
Main Fire Alarm Chassis (FX-2003/9[S]-12) Polarity Reversal and City Tie Module (PR-300)
Same as FX-2003-6 except:
AC Line Voltage: 120V 60Hz / 240V 50Hz
4 Amps. / 2 Amps. (primary)
Power Supply ratings: 12 Amps. Max. (secondary)
For Indicating Circuits: 24VDC unfiltered
10 Amps. max.
Battery: 24VDC, Gel-Cell Lead-Acid
Charging capability: 17-55 AH batteries
Supervised city tie--not power limited
24VDC unfiltered, 210 mA max., Trip coil: 14 ohms.
Terminals are labelled "City Tie".
Polarity reversal power limited
Terminals are labelled "Polarity Reversal".
24VDC open
12VDC @ 3.5 mA, 8 mA max. (shorted)
Current Consumption: standby: 35 mA
alarm: 300 mA
