FX-2000 Series Installation and Operation Manual
71
Appendix D: Remote Annunciator Panels
RA-1000 & RAM-200 Series
The RA-1000 Series of remote annunciators are units with electrical modules and enclosures matching the
configurations of the FA-1000 Series Fire Alarm Control Panels. For detailed information see Mircom Documents
RA-1000 Manual LT-617, RAM-208 Manual LT-648, RAM-216 Manual LT-658 and MGD-32 Manual LT-847.
Models
• RAM-1032(TZ) Main Annunciator Chassis with common indicators and controls, and 32-circuit capacity
• RAX-1048(TZ) Adder Annunciator Chassis with 48 circuit capacity
• RAM-1016 Non-Expandable Annunciator Chassis with common indicators and controls, and 16-circuit capacity
• RAM-208 Non-Expandable Annunciator Chassis with limited common indicators and controls, and eight-circuit
capacity
• RAM-216 Non-Expandable Annunciator Chassis with limited common indicators and controls, and 16-circuit
capacity
Graphic Annunciators
• MGD-32 Main Graphic Annunciator Chassis with common indicators and controls, and 32-circuit capacity
• AGD-048 Adder Graphic Annunciator Chassis with 48-circuit capacity
Enclosures
• BB-1001 with capacity for one annunciator chassis
• BB-1002 with capacity for two annunciator chassis
• BB-1003 with capacity for three annunciator chassis
• BB-1008 with capacity for eight annunciator chassis
• BB-1012 with capacity for twelve annunciator chassis
RAX-LCD:
The RAX-LCD Remote Shared Display is a remote annunciator that provides the same functions as the main
display on the fire alarm control panel, less 16 zone LEDs. It is equipped with a large 4 line x 20 character backlit
alphanumeric LCD display which uses a simple menu system complete with a directional key pad and switches for
Enter, Menu, Cancel and Info. For more information see Mircom document LT-856.
Models
• RAX-LCD: Main Annunciator Chassis with Common Indicators and Controls.
• RAX-1048(TZ): Adder Annunciator Chassis with 48 Circuit Capacity.
• IPS-2424: Programmable Input Switches module with 48 display points and 24 buttons.
ENCLOSURES:
• BB-1001 With capacity for one Annunciator Chassis.
• BB-1002 With capacity for two Annunciator Chassis.
• BB-1003 With capacity for three Annunciator Chassis.
Notes:
• Finish: Painted, textured, off-white (standard) (for other paint available colours and finishes, please
contact factory)
• Material:18 G.A. cold roll steel (CRS)
