Mircom FX-2000 User Manual

Appendix A: Specifications
60
Fan Damper Display Module (FDX-008/FDX-008KI) Detection Adder Module (DM-1008A)
FDX-008 Fan Damper Control
24V DC nominal, range of 20 to 39V DC.
Interconnects via one ribbon cable to P2 of previous display
module.
Provides eight configurable output circuits or fan damper
controls.
Current Consumption: standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
FDX-008KI Fan Damper Control with Keyswitch
24V DC nominal, range of 20 to 39V DC.
Interconnects via one ribbon cable to P2 of previous display
module.
Provides eight configurable output circuits or fan damper
controls, 1 output controlled via keyswitch.
Current Consumption: standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
Eight supervised Class B (Style B) or four Class A (Style D)
initiating circuits; fully configurable. Terminals are labelled
"INI".
Initiating circuits are Compatibility ID "A".
Current Consumption: standby: 80 mA
alarm: 1 zone active: 125 mA
2 zone active: 170 mA
4 zone active: 275 mA
6 zone active: 370 mA
8 zone active: 465 mA
Adder Annunciator Chassis (RAX-1048[TZ])
48 Display Points (TZ version has 48 extra trouble display
points). Interconnect via one ribbon cable to RAM-1032(TZ) or
to previous RAX-1048(TZ). Annunciation of up to 48 additional
points (with trouble annunciation on the TZ version).
Current Consumption: standby: 22 mA
alarm: 1 zone LED active: 26 mA
2 zone LED active: 30 mA
3 zone LED active: 35 mA
4 zone LED active: 39 mA
48 zone LED active: 262 mA
Digital Communicator Module (UDACT-300A) Programmable Input Switches Module (IPS-2424)
Transmit alarm, supervisory, and trouble to a central
monitoring station.
Current Consumption: standby: 45 mA
alarm: 120 mA
Current Consumption: standby: 10 mA
alarm (one zone active): 15 mA
Compliance
System Model: FX-2000 Series Fire Alarm Control Panel
System Type: Local, auxiliary (using PR-300), remote protected premise station (using PR-300 or
UDACT-300A), central station protected premises (using UDACT-300A).
Type of Service: A, M, WF, SS (with PR-300 or UDACT-300A)
Type of Signalling: Non-coded
Applicable Standards: NFPA 70 and 72, UL-864 Rev.9, ULC S-524, ULC S-527-99
