Appendix B: Compatible Devices
64
FX-2000 Series Compatible Four-W
ire Smoke Detectors (UL Listed)
Make & Model
# of Devices
/Circuit
Make & Model
# of Devices
/Circuit
Mircom
System Sensor
MIR-545U
30
1424
25
MIR-545TU
30
6424
30
Sentrol-ESL
6424A
30
541C
N/A
A77-716B
541CXT
N/A
DH400ACDCI
8
709-MV
-21
N/A
DH4
00ACDCP
8
709-24V
-21
N/A
DH400ACDCIHT
8
741U WITH 702U or
702E Base
N/A
449A
T
, 449C, 44
9CT
, 449CRT
,
449CST
, 449CSTE, 449CSRT
,
449CSRH, 449CSST
, 449CSSTE,
449CTE, 449CSL
T
N/A
69
71
Table of Contents
Default Chapter
3
Table of Contents
3
Introduction
7
About the FX-2000
7
Overall Features
7
Document Conventions
8
Circuits and Zones
8
Wiring Styles
8
System Components
9
Chassis Types
9
Adder Modules
9
Auxiliary Models
10
Enclosures
10
Flush Trim Rings
10
Remote Annunciators
11
Batteries
11
FX-2000 Accessories
11
Mechanical Installation and Dimensions
12
Figure 2: BBX-1072A Flush or Surface Enclosure Installation and Dimensions
13
Figure 3: BB-5008 Enclosure Installation Instructions and Dimensions
14
Chassis Installation
15
Figure 5: Chassis Installation into BBX-1072A
16
Figure 6: Installation Instructions and Dimensions for BB-5014
17
Module Mounting Locations
18
Display and Adder Modules Mounting Locations
19
FX-2003-6/FX-2003-12 Compact Main Chassis
19
FX-2017-12 MID-Size Main Chassis
20
FX-2009-12 Large Main Chassis
20
ECX-0012 Expander Chassis for FX-2009-12
20
Module Settings
22
Main Fire Alarm Modules (MD-764 Part of Main Chassis)
22
Main Fire Alarm Super Module (MD-757 Part of "S" Version Main Chassis)
23
Figure 11: Main Display Module (Part of Main Chassis)
24
Figure 13: IPS-2424 Programmable Input Switches Module
25
Figure 15: FDX-008 Block Diagram of Fan and Monitor Setup
26
Figure 16: FDX-008KI Fan Damper Control Display Module
27
Figure 17: Hardwire Detection Adder Module (DM-1008A)
28
Polarity Reversal and City Tie Module (Model PR-300)
30
Udact-300A Main Board
31
Table 2: Cable Connectors and Miscellaneous
32
ALC-198S Single Intelligent Analog Loop Controller Module
33
Figure 22: ALC-198S Single Intelligent Analog Loop Controller Module
34
ALC-396S Dual Intelligent Analog Loop Controller Module
35
Figure 23: ALC-396S Dual Intelligent Analog Loop Controller Module
36
ALC-H16 Hardwire Loop Controller Module
37
Figure 24: ALC-H16 Hardwire Loop Controller Module
38
Field Wiring
39
Main Fire Alarm Module Terminal Connections
39
Figure 26: Main Fire Alarm Module Terminal Connections (Continued)
40
Analog Loop Wiring
41
Figure 28: Loop Terminal Connections - Style 7
42
Figure 29: Loop Terminal Connections - Style 6 (Formerly Class A)
43
Figure 30: Single Loop Terminal Connections - Class B
44
Figure 31:Single Loop Terminal Connections - Style 7
45
Figure 32: Single Loop Terminal Connections - Style 6
46
Detection Module (DM-1008A) Terminal Connections
47
Signal Module (SGM-1004A) Terminal Connections
48
Relay Module (RM-1008(A)) Terminal Connections
49
Polarity Reversal and City Tie Module (PR-300) Wiring
50
UDACT-300A Main Board Terminal Connections
51
Power Supply Connections
52
Wiring Tables and Information
53
Table 7: Analog Loop Wiring
54
System Checkout
55
Before Turning the Power on
55
Power-Up Procedure
55
Troubleshooting
55
Indicators, Controls, and Operation
56
Common Indicators
57
Common Controls
58
Single Stage Operation
60
Two Stage Operation
60
Pre-Signal Operation
61
Circuit Types
62
Appendix A: Specifications
65
Compliance
66
Appendix B: Compatible Devices
67
FX-2000 Series Compatible Addressable Loop Modules (UL)
67
FX-2000 Series Compatible Two-Wire Smoke Detectors (UL Listed)
68
FX-2000 Series Compatible Four-Wire Smoke Detectors (UL Listed)
70
FX-2000 Series Compatible Signalling Devices (UL Listed)
71
FX-2000 Series Compatible Addressable Loop Modules (ULC)
72
FX-2000 Series Compatible Hardwire Smoke Detectors (ULC Listed)
73
FX-2000 Series Compatible Synchronized Modules and Strobes
75
Appendix C: Power Supply and Battery Calculations
76
Appendix D: Remote Annunciator Panels
77
RA-1000 & RAM-200 Series
77
Rax-Lcd
77
Appendix E: DIP Switch Settings Summary
78
Appendix F: Alarm Verification Timing
81
Warranty & Warning Information
83
Warning Please Read Carefully
83
Limited Warranty
85
Warranty Procedure
85
Disclaimer of Warranties
85
Out of Warranty Repairs
86
