Indicators, Controls, and Operation
58
Evacuation Codes
Single stage codes
Two-stage codes:
Figure 41: Evacuation Codes
Continuous On 100% of the time
Temporal Code 3 of 0.5 second on, 0.5 second off then, 1.5 second pause
March Code 0.5 second on, 0.5 second off
California Code 5 seconds on, 10 seconds off
Alert Code 0.5 second on, 2.5 seconds off
General Alarm Evacuation code as selected from above.
0.5s
0.5s
1.5s
0.5s
0.5s
5s 10s
CONTINOUS
TEMPORAL CODE
MARCH CODE
CALIFORNIA CODE
0.5s
2.5s
ALERT CODE

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mircom FX-2000 and is the answer not in the manual?

Mircom FX-2000 Specifications

General IconGeneral
TypeFire Alarm Control Panel
Maximum devices per loop99
Power Supply120 VAC, 60 Hz
Battery Backup24VDC, 7Ah
ProgrammingVia PC
SLC Loops1
Operating Temperature0°C to 49°C (32°F to 120°F)
CompatibilityMircom devices
DisplayLCD
