FX-2000 Series Installation and Operation Manual
23
JW1: Remove continuity jumper if this is not the last adder module installed.
JW2: Jumper pins for bell cut or isolators on Zone 1.
JW3: Jumper pins for bell cut or isolators on Zone 2.
JW4: Jumper pins for bell cut or isolators on Zone 3.
JW5: Jumper pins for bell cut or isolators on Zone 4.
JW11: For basic operation do not wire these terminals.
Components
There are four green LEDs on the board, one for each signal zone. The LED will illuminate or flash following the
signal rate sent to its zone. It will be off when the system is normal and they will illuminate when a signal zone is
activated. The LED does not reflect what is happening on the signal zone, just that it is receiving data to activate
that signal zone.
Operation
There are three modes of operation for this module. The basic mode of operation does not involve any bell cut relay
or isolators connected to the signal zones. For this case, leave jumpers JW2, JW3, JW4 and JW5 as they come on
pins 2 and 3, and do not make any connection to terminal block J11. The second mode provides bell cut operation
which allows the silencing of the bells. The third mode is used when isolators are to be connected to the signal
circuits. For further information on bell cut relays or isolators, please refer to the specific fire alarm panel manual or
the isolator instruction manual.
Jumpers for the Bell Cut Mode
JW2: Place jumper over pins 1 and 2 for the ability to remotely silence the bells on Zone 1.
JW3: Place jumper over pins 1 and 2 for the ability to remotely silence the bells on Zone 2.
JW4: Place jumper over pins 1 and 2 for the ability to remotely silence the bells on Zone 3.
JW5: Place jumper over pins 1 and 2 for the ability to remotely silence the bells on Zone 4.
J11: Wire these terminals to a bell cut relay (for details see QRM-1001 Bell Cut Module Installation and Operating
Instructions, LT-666).
Jumpers for the Isolator Mode
JW2: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 1.
JW3: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 2.
JW4: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 3.
JW5: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 4.
J11: Wire these terminals to an alarm relay. These may be tapped if more signal modules are used in this manner.
Note: Jumpers JW2, JW3, JW4 and JW5 are positioned on pins 2 and 3 (right two pins with board
orientation as shown above) from factory.
ATTENTION: Discard jumpers on zones that are not configured for bell cut.
ATTENTION: Discard jumpers on zones that are not configured for isolators.
