Mircom FX-2000 User Manual

Appendix E: DIP Switch Settings Summary
74
ALC396S
ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
1 OFF ON ON ON ON ON ON
Put in "OFF" position for firmware restore to defaults during
power up. At all other times put in "ON" state.
2 ON OFF ON ON ON ON ON
3 OFFOFFONONONONON
4 ON ON OFF ON ON ON ON
5 OFFONOFFONONONON
6 ONOFFOFFONONONON
7 OFF OFF OFF ON ON ON ON
8 ON ON ON OFF ON ON ON
9 OFF ON ON OFF ON ON ON
10 ON OFF ON OFF ON ON ON
11 OFF OFF ON OFF ON ON ON
12 ON ON OFF OFF ON ON ON
13 OFF ON OFF OFF ON ON ON
14 ON OFF OFF OFF ON ON ON
15 OFF OFF OFF OFF ON ON ON
16 ON ON ON ON OFF ON ON
17 OFF ON ON ON OFF ON ON
18 ON OFF ON ON OFF ON ON
19 OFF OFF ON ON OFF ON ON
20 ON ON OFF ON OFF ON ON
21 OFF ON OFF ON OFF ON ON
22 ON OFF OFF ON OFF ON ON
23 OFF OFF OFF ON OFF ON ON
24 ON ON ON OFF OFF ON ON
25 OFF ON ON OFF OFF ON ON
26 ON OFF ON OFF OFF ON ON
27 OFF OFF ON OFF OFF ON ON
28 ON ON OFF OFF OFF ON ON
29 OFF ON OFF OFF OFF ON ON
30 ON OFF OFF OFF OFF ON ON

Mircom FX-2000 Specifications

General

Type	Fire Alarm Control Panel
Maximum devices per loop	99
Power Supply	120 VAC, 60 Hz
Battery Backup	24VDC, 7Ah
Programming	Via PC
SLC Loops	1
Operating Temperature	0°C to 49°C (32°F to 120°F)
Compatibility	Mircom devices
Display	LCD
