Chapter 9
154
Logic programming – Function blocks
9.7.18 Routing N:N
Function block diagram
General description
The Routing N:N function block passes up to eight input signals parallel to up to eight
outputs. The input signal can originate from a preceding function block or directly from
a physical input.
Parameters of the function block
Parameter Possible values
Number of inputs 1 to 8
Invert input x Each input of this function block can be inverted (see Section 9.5.2).
Figure 131:
Function block diagram for
the Routing N:N function
block
Table 62:
Parameters of the Routing
N: N function block
