Chapter 7
92
Flexi Link
Verify the configuration
Switch to the Hardware configuration view for any station in your project. If the
device configuration is valid and equal with the configuration in the Setting and
Monitoring Tool, but not yet verified, the CV LED on the CPU module will flash as
well as the Upload and verify configuration button on the left side of the
configuration area.
Click the Upload and verify configuration button. The Setting and Monitoring
Tool will upload the configuration from the module and compare it to the
configuration in the Setting and Monitoring Tool. If both configurations match, the
result will be displayed as a report and you will be asked whether you want to set
the device to Verified. Read the report carefully.
You can print the report or save it in PDF format.
If you have checked the report and want to set the device to Verified, click Yes.
The device will be set to Verified. If it is currently not in the Run state you will now
be asked whether you want to start it.
Repeat this for all stations in your Flexi Link system.
For more detailed information on transferring and verifying a configuration please see
Chapter 10.
