4G9 ENGINE (E-W) -
Alternator and Ignition System
11A-3-7
REMOVAL SERVICE POINT
A
A
"
CRANKSHAFT BOLT REMOVAL
(1) Use the special tool to hold the flywheel or the drive
plate, and then loosen the crankshaft mounting bolts.
INSTALLATION SERVICE POINTS
"
A
A
CAM POSITION SENSOR SUPPORT
INSTALLATION
(1) Apply a 3 mm bead of form-in-place gasket (FIPG) to
the area shown.
Specified sealant:
Mitsubishi Genuine Part No. MD970389 or
equivalent.
"
B
A
CRANKSHAFT BOLT INSTALLATION
(1) Use the special tool to hold the flywheel or the drive
plate, and then tighten the crankshaft mounting bolts.
MD998781
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Added
MD998781
