4G9 ENGINE (E-W) -
Specifications
11A-1-5
Items Nm
Ignition failure sensor 23
Cam position sensor 9
Cam position sensor support 13
Cam position sensing cylinder 21
Engine cover 2.9
Timing belt
Camshaft sprocket bolt 88
Cam position sensor <DOHC> 9.8
Crank angle sensor 9.8
Timing belt rear cover 11
Timing belt tensioner 24
Engine support bracket, right 49
Accessory mount 49
Timing belt cover 11
Tensioner pulley bolt 49
Tensioner arm bolt 44
Auto-tensioner bolt 13
Idler pulley bolt 36
Fuel system and emission system
Breather tube 21
Fuel pump 18
Carburetor 17
EGR valve 21
Fuel return pipe 9
Delivery pipe 12
Fuel pressure regulator 9
Throttle body stay 23
Throttle body 19
Vacuum hose and pipe assembly <SOHC-MPI for other than PAJERO io> 10
Vacuum hose and pipe assembly <SOHC-MPI for PAJERO io> 9
Solenoid valve assembly <SOHC- MPI for other than PAJERO io> 11
Solenoid valve assembly <SOHC-MPI for PAJERO io> 9
Throttle body and EGR system (GDI)
Air intake resonator 9
Intake manifold stay 30
Water hose clamp 13
Water pipe 11
Throttle body 18
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised
