4G9 ENGINE (E-W) -
Fuel and Emission Control System
11A-5-4
REMOVAL AND INSTALLATION <DOHC>
11 Nm
18 Nm
10 Nm
9Nm
9Nm
15
14
9
12
11
13
1
10
6
7
8
3
2
5
16
23 Nm
4
4
23 Nm
Removal steps
1. Vacuum pipe assembly
2. Throttle body assembly
"
C
A 3. Gasket
4. Throttle body stay (MIVEC)
5. Vacuum hose
6. Fuel hose
"
B
A 7. Fuel pressure regulator
8. O-ring
9. Delivery pipe and injector
10. Insulator
11. Insulator
"
A
A 12. Injector
13. O-ring
14. Grommet
15. Delivery pipe
16. Fuel return pipe
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised
