Alternator and Ignition System
11A-3-1
PWEE9502-A
E
Nov. 1995Mitsubishi Motors Corporation
Revised
3. ALTERNATOR AND IGNITION SYSTEM
REMOVAL AND INSTALLATION <SOHC> (Engines with distributor)
10 Nm
23 Nm
25 Nm
12 Nm
23 Nm
49 Nm
44 Nm
181 Nm
3
2
8
7
9
10
4
1
5
6
Removal steps
1. Drive belt*
2. Alternator
3. Alternator brace
A
A
""
B
A
4. Crankshaft bolt
5. Crankshaft pulley
6. Flange
7. Spark plug cable
8. Spark plug
9. Distributor
10. O-ring
NOTE:
*: For details of adjustment, refer to the relevant model’s
chassis workshop manual.
