Mitsubishi 4G9 series

4G9 ENGINE (E-W) -
Timing Belt
11A-4-3
PWEE9502-A
E
Nov. 1995Mitsubishi Motors Corporation Revised
REMOVAL SERVICE POINTS
A
A
"
TIMING BELT REMOVAL
(1) Mark belt running direction for reinstallation.
A
B
"
CAMSHAFT SPROCKET BOLT REMOVAL
<With rocker cover removed> (Except SOHC)
(1) Use a wrench to hold the hexagonal part of the camshaft,
and then remove the camshaft sprocket mounting bolt.
INSTALLATION SERVICE POINTS
"
A
A
CAMSHAFT SPROCKET BOLT INSTALLATION
MD998719
or
MD998754
MB990767
MB990767
MD998719
or
MD998754
