Mitsubishi 4G9 series

4G9 ENGINE (E-W) -
Throttle Body and EGR System (GDI)
11A-5a-3
INSTALLATION SERVICE POINTS
"
A
A
THROTTLE BODY GASKET
"
B
A
INTAKE MANIFOLD STAY INSTALLATION
(1) Tighten the four bolts at the top and bottom of the stay
handtight.
(2) Check that the stay seating surface is in close contact
with the bosses on t he intake manifold and the cylinder
block.
(3) Tighten the four bolts to the specified torque.
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Added
Tab
<CARISMA>
<PAJERO io>
Intake manifold
Cylinder block
Intake
manifold
stay
Bolt
Bolt
