4G9 ENGINE (E-W) -
Cylinder Head and Valves
11A-9-4
PWEE9502-A
E
Nov. 1995Mitsubishi Motors Corporation Revised
REMOVAL SERVICE POINTS
A
A
"
CYLINDER HEAD BOLT REMOVAL
(1) Loosen the cylinder head bolts using the special tool.
A
B
"
RETAINER LOCK REMOVAL
(1) Store the removed valves, springs and other parts, tagged
to indicate their cylinder No. an d location to aid
reassembly.
SOHC
MB991653
DOHC, MIVEC
MB991653
MD998772
Except MIVEC
MD998784
MD998772
MIVEC
MD998735
To Next Page
