Mitsubishi MT300 User Manual

System description
-
111
-
'10 • HM-T-149
General
Explanation
External
Mixing valveQN11
Shuttle valve for heating/coolingQN12
Non-return valveRM
Expansion vesselCM1
Heating system 2EP21
Circulation pump, external 1GP10
External controlKF
Flow indicatorPG1
Room sensor MH-RG 10 (accessory)MH-RG10
Buffer vessel (accessory)CP1
Safety valveFL1
Mixer valve, HWFQ1
Indoor unit
Temperature sensor, outdoor air (external)BT1
Temperature sensor, supplyBT2
Temperature sensor, heat exch. in (Twin)BT3
Temperature sensor, tank waterBT6
Temperature sensor, heat exch. out (Twout)BT12
Temperature sensor, liguid pipe (Thi-L)BT15
Temperature sensor, immersion heaterBT19
Temperature sensor, external heat sourceBT24
Thermostat, standby modeBT30
Temperature limiterFD1
High pressure sensorBP4
Mixing valveQN11
Reversing valve, hot waterQM30
Reversing valve, climate systemQM31
Filter dryer (refrigerant)HS1
Immersion heaterEB1
Heat exchangerEP2
Circulation pump, climate systemGP1
Particle (water)HQ1
Safety valve, tankFL2
Pressure gaugeBP5
Sanitary cold water inletCW
Sanitary hot water outletHW
Outdoor unit
Temperature sensor, outdoor airTho-A
Temperature sensor, hot gasTho-D
Temperature sensor, heat exchanger outTho-R1
Temperature sensor, heat exchanger, inTho-R2
Temperature sensor, suction gasTho-S
Low pressure sensorLPT
High pressure switch63H1
Current sensorCT
Expansion valve, coolingEEV-C
Expansion valve, heatingEEV-H
Fan motorFMo1
4-way valve20S
Compressor motorCM
Valve, solenoidSV
