Pump capacity diagram
<HMA100V, HMA100VM>
0
10
20
30
40
50
60
0 200 400 600 800 1000 1200 1400 1600 1800 2000
dp [kPa]
kPa
Flow ℓ/h
Available pressure
<HMS140V>
Connection of extra circulation pump
When connectingextra circulation pumps, requirements for
pressure, maximum flow etc mustbe met.Seepage67for
location.
Connecting the climate system
Pipe connections for the climate system are made at the top.
■ Allrequiredsafetydevicesandshut-offvalves(installedas
closetotheindoorunitaspossible)mustbetted.
■ Installthebleedvalveswhere necessary,highestpointof
the water system in usual case.
■ Thesafetyvalve(FL2)mustbeinstalledasillustrated.The
entire length of the overflow water pipe from the safety
valves must be inclined to prevent water pockets and must
also be frost proof.
■ Theendofoverflowpipefromthe safetyvalvesmustbe
left open to the atmosphere. The water may drip from the
pipe.
0
10
20
30
40
50
60
70
80
0 500 1000 1500 2000 2500 3000 3500
Flow ℓ/h
kPa
Available pressure
Indoor unit installation
■ HT30 doesn't have a port for FL2. Safety valve should be
installed on site.
■ HMS140Vneedsto connect a buffervesselon the hot
water tank even if hot water supply is not necessary.
See connecting the hot water heater for details.
<HMA100V, HMA100VM>
FL2BP5
<HMS140V>
<MT300>
<MT500>
■ When connecting to a system with thermostats on all
radiators,anoverflowvalvemustbef itted,orsomeofthe
thermostatsmustberemovedtoensuresufcientow.
■ SeesectionDockingsonpage66foroutlinediagram.
To climate system
To XL24 on tank (Circulation return)
From Climate system
From XL23 on tank (Circulation supply)
FL2
NOTE
Over f low valve must be installed in case extra circulation
pump is used.
The circulation pump may become damaged.
FL2
