Technical data
Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V
Outdoor Model FDCW71VNX FDCW100VNX FDCW140VNX
Power source
1 phase 230V 50Hz/
3 phase 400V 50Hz
3 phase 230V 50Hz
1 phase 230V 50Hz/
3 phase 400V 50Hz
3 phase 230V 50Hz
1 phase 230V 50Hz/
3 phase 400V 50Hz
Heating Nominal capacity
condition 1 kW 8.0 (3.0 - 8.0) 9.0 (3.5 - 12.0) 16.5 (5.8 - 16.5)
condition 2 kW 8.3 (2.0 - 8.3) 9.2 (3.5 - 10.5) 16.5 (4.2 - 17.2)
Heating power consumption
condition 1 kW 2.40 2.50 4.98
condition 2 kW 2.03 2.07 3.93
COP
condition 1 3.33 3.60 3.31
condition 2 4.08 4.44 4.20
Cooling Nominal capacity
condition 1 kW 7.1 (2.0 - 7.1) 8.0 (3.0 - 9.0) —
condition 2 kW 10.7 (2.7 - 10.7) 11.0 (3.3 - 12.0) 16.5 (5.2 - 16.5)
Cooling power consumption
condition 1 kW 2.65 2.85 —
condition 2 kW 3.19 3.04 4.60
EER
condition 1 2.68 2.81 —
condition 2 3.35 3.62 3.59
Tapping capacity
12liter/min liter 270 270 —
16liter/min liter 200 200 —
Operation range
(Outdoor temperature)
heating -20 - 43
cooling 15 - 43
Operation range
(Water temperature)
heating 25 - 58 (65 with immersion heater)
cooling 7 - 25 18-25
System water ow l/s 0.19 - 0.38 0.24 - 0.57 0.40 - 0.79
Max current A
44/
16
30
44/
16
30
50/
25
Recommended fuse rating A
50/
16
32
50/
16
32
63/
25
Starting current A 5
Deviation, incoming supply -15 - +10%
Max refrigerant pipe length m 30 12 30
Max height difference between IU and OU m 7
Height mm 1760 (+20 - 50mm, adjustable feet) 1004
Width mm 600 513
Depth mm 650 360
Weight (without water in the system) kg 140 60
Color White
IP Grade IP21
Immersion heater 9kW 4steps (2, 4, 6, 9) —
Output W 9-63 (variable speed) 9-110 (variable speed)
Max available external pressure kPa 57 61
Max ow l/s 0.54 0.78
Flow at 20kPa pressure drop l/s 0.45 0.67
Emergency mode thermostat
℃
35/45 —
Temperature limiter
℃
98(-8) —
Safety valve MPa 0.25 —
Volume total liter 270 ±5% —
Volume hot water coil liter 14 —
Material hot water coil Stainless steel —
Max pressure, tank MPa 0.25 —
Max pressure, hot water coil MPa 1.0 —
Water quality, domestic hot water
≦
EU directive no 98/83/EF —
Volume expansion vessel liter — 18
Ambient temperature, indoor module
℃
5-35, RH95%
Dimensions, climate system pipe mm 22 28
Dimensions, hot water pipe mm 22 —
Water pipe connection Compression ttings
External heat source connection ISO 228/1 G1 internal —
