'10 • HM-T-149
Technical data
Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V
Outdoor Model FDCW71VNX FDCW100VNX FDCW140VNX
Height mm 595 845 1300
Width mm
780
(+67 with valve cover)
970 970
Depth mm 340 370
(+80 with foot rail)
370
(+80 with foot rail)
Weight kg 60 81 105
Color Stucco White
Sound Power level* dB(A) 64 64.5 71
Sound Pressure level** dB(A) 48 50 54
Airow m3/min 50 73 100
Type of compressor RMT5118MDE2 RMT5126MDE2 RMT5134MDE2
Refrigerant oil liter 0.68 M-MA68 0.9 M-MA68 0.9 M-MA68
Heat exchanger M n & inner grooved tubing straight n & inner grooved tubing M n & inner grooved tubing
Ref control EEV
Defrost control Reversing cycle
Fan Propeller fan x 1 Propeller fan x 2
Fan motor W 86 x 1 86 x 1 86 x 2
Shock & vibration absorber Rubber sleeve (for compressor)
Electric heater (crank case) W 20
Safety equipment
Internal thermostat for fan motor
Abnormal discharge temperature protection
Power and signal line from indoor unit 5 core 2.5mm2 5 core 2.5mm2 3 core 6mm
2
+
3 core 1.5mm
2
Refrigerant R410A
Refrigerant volume
(pipe length without additional charge)
kg (m) 2.55 (15) 2.9 (12) 4.0 (15)
Dimensions, refrigerant pipe mm (inch) Gas pipe: OD 15.88 (5/8"), Liquid pipe: OD 9.52 (3/8")
Ref pipe connections Frare
Accessories Base heater (50W)
Outdoor Unit
Model HT30 MT300 MT500
Power source 1phase 230V / 3phase 400V 50Hz
Volume liter 30 300 500
Volume hot water coil liter — 14 21
Material hot water coil — Stainless steel
Tapping capacity
12liter/min liter — 320 TBD
16liter/min liter — 230 TBD
Immersion heater kW 9kW 4steps
Height mm 358 1880 1695
Width mm 593 597 759
Depth mm 360 598 879
Weight kg 23 110 131
IP grade IP21
Color White
Emergency mode thermostat
℃
35/45
Temperature limiter
℃
98 (-8)
Safety valve MPa 0.25
Max pressure, Tank MPa 0.25
Max pressure, hot water coil MPa — 1.0
Water quality, domestic hot water —
≦
EU directive no 98/83/EF
Dimensions, climate system pipe mm(inch) 25.4(1") 28
Dimensions, hot water pipe mm(inch) — 25.4(1")
Max water pipe length to indoor unit m 10
Max wiring length to indoor unit m 10
Water pipe connection, climate system ISO 228/1 G1 external Compression fitting
Water pipe connection, hot water — ISO 228/1 G1 external
External heat source connection — ISO 7/1 R1 int ISO 228/1 G1 int
Tank Unit (for HMS140V only)
Specifications
Test condition for sound pressure level**
Temperature condition: Heating condition 1
MIC position: 1m away in front of outdoor unit at the height of 1m
Test conditions
Water Temperature Ambient Temperature
Heating
condition 1 45
℃
out / 40
℃
in
7
℃
DB / 6
℃
WB
condition 2 35
℃
out / 30
℃
in
Cooling
condition 1 7
℃
out / 12
℃
in
35
℃
DB
condition 2 18
℃
out / 23
℃
in
Tapping 40
℃
out / 15
℃
in 7
℃
DB / 6
℃
WB
