NICE5000 User Manual 4 Use of the Commissioning Tools
- 75 -
•
LED Display
The ve-digit LED data display can show the following range of information:
- Parameter value
- Monitoring information
- Fault code
4.2.2 Description of Keys on the Operation Panel
Table 4-1 Description of keys on the operation panel
Key Name Function
PRG
Programming Enter or exit Level-I menu.
ENTER
Conrm
Enter the menu interfaces level by level, and conrm the
parameter setting.
Increment Increase data or function code.
Decrement Decrease data or function code.
Shift
Select the displayed parameters in turn in the stop or
running state, and select the digit to be modied when
modifying parameters.
RUN
Run Start the controller in the operation panel control mode.
STOP
RES
Stop/Reset
Stop the controller when it is in the running state and
perform the reset operation when it is in the fault state.
QUICK
Quick Enter or exit Level-I quick menu.
MF.K
Fault hiding
Press this key to display or hide the fault information in
the fault state, which facilitates parameter viewing.
4.2.3 Operation Procedure
The LED operation panel adopts three-level menu.
The three-level menu consists of function code group (Level I), function code (Level II), and
function code setting value (level III), as shown in the following gure.
