Moog MSD G393-004 User Manual

moog
MSD Servo Drive DC-AC Operation Manual
[]
Mechanical
installation
13
Id.-No.: CA97554-001 Date: 06/2012
to glossaryto table of contents
NOTE: The minimum clearance specified in the table applies to devices
of the same power output. Arrange devices with different drive
power in descending order of power output (e.g. viewed from the left
Size4-Size3-Size 2-Size 1). This minimizes the mutual thermal influence. The
supply unit must always be arranged on the side of the most powerful DC-AC
servo drive.
A
D
C1C1
TBD
CH1 H
H2
Size 1
Size 2 ... Size 6
D
A
C
Fig. 2.1 Dimensional drawing, air-cooled housing
G
F
F
E
Fig. 2.2 Mounting clearance, air-cooled housing
