MSD Servo Drive DC-AC Operation Manual
16
Id.-No.: CA97554-001 Date: 06/2012
to glossaryto table of contents
2.4 Alignment and arrangement in a group
MSD Power
Supply Unit
Size 5
MSD Servo Drive DC-AC
Size 4
MSD Servo Drive DC-AC
Size 3
MSD Servo Drive DC-AC Size 1
MSD Servo Drive DC-AC
Size 2
Fig. 2.5 Alignment DC-AC servo drive on power supply unit Size 5 (example)
18.5 mm
MSD Power Supply unit
Size 6A
MSD Servo Drive DC-AC
Size 5
MSD Servo Drive DC-AC
Size 4
MSD Servo Drive DC-AC
Size 3
MSD Servo Drive DC-AC Size 1
Fig. 2.6 Alignment DC-AC servo drive on power supply unit Size 6A (example)
