MSD Servo Drive DC-AC Operation Manual
[]
Appendix
Project planning
67
Id.-No.: CA97554-001 Date: 06/2012
to glossaryto table of contents
In addition to the total power tap, the total DC link capacitance of the axis network also
needs to be considered. The maximum total DC link capacitance of the AC-AC servo
drive must not be exceeded. In this regard refer to tableA.6 and to tableA.5 on page
65:
AC-AC servo
drive
internal
DC link capacitance [µF]
max. total
DC link capacitance [µF]
Air cooling Liquid cooling
Mains voltage
400VAC
Mains voltage
460VAC or
480VAC
G392-004 400 - 800 800
G392-006 400 - 800 800
G392-008 725 - 1355 1355
G392- 012 725 - 1355 1355
G392-016 / G395-016 1230 1230 2460 1734
G392-020 / G395-020 1230 1230 2460 1734
G392-024 / G395-024 2000 2000 2504 2000
G392-032 / G395-032 2000 2000 2504 2000
G392-045 / G395-053 430 430 5100 5100
G392-060 / G395-070 900 900 5100 5100
G392-072 / G395-085 900 900 5100 5100
G392-090 / G395-110 1060 2120 9200 9200
G392-110 / G395-143 2120 2120 9200 9200
G392-143 / G395-170 3180 4240 9200 9200
G392-170 / G395-210 4240 4240 9200 9200
G395-250 - 3600 60000 60000
G395-325 - 5400 60000 60000
G395-450 - 7200 60000 60000
Table A.6 DC link capacitance and Maximum total DC link capacitance of the AC-AC servo drives
!
ATTENTION!
• Observe switching on sequence
The mains voltage is only allowed to be switched on after switching on the
24 V DC supply voltage for the control electronics and conclusion of the
initialisation phase.
• Observe power classes
It is only allowed to connect DC-AC servo drives of lower or the same
power class to an AC-AC servo drive.
• Observe maximum number of axes
It is allowed to operate a maximum of six DC-AC servo drives on one sup-
plying AC-AC servo drive.
Calculation example: Feed from a AC-AC servo drive
Two DC-AC servo drives G393-024, two DC-AC servo drives G393-060 and one
DC-AC servo drive G393-090 (air-cooled) are to be connected to an AC-AC servo drive
G392-170.
Calculation: 1 x 4240µF + 2 x 504µF + 2 x 900µF + 1 x 1060µF = 8108µF
Result: The AC-AC servo drive is adequately dimensioned with a maximum
total DC link capacitance of 9200µF.
NOTE: Note that not only the DC link capacitances of the DC-AC servo drives,
but also of the supplying AC-AC servo drive, need to be considered.
A.7.7 External components
When using a AC-AC servo drive as the supply source you will need additional compo-
nents:
• Mains filter
• Mains choke
• Braking resistor
• EMC fixings
See MSD Servo Drive Ordering Catalog (Id.-No.: CDL 29950-en).
