B.1.6 Size 3 and Size 4 (liquid-cooled, 400VAC)
Type
Power stage
switching
frequency
Ambient
temperature
Rated current
Peak current
1)
I
MAX
0Hz
I
1MAX
≥5Hz
t
1
2)
I
2MAX
≥5Hz
t
2
2)
[kHz] [°C]/[°F] [A
eff
] [A
eff
] [A
eff
] [s] [A
eff
] [s]
G397-020
(Size 3)
4
+4 0/+104
20.0 33.6 33.6
10
48.0 0.5
8 20.0 33.6 33.6 - -
12 17.4 26.4 26.4 - -
16 12.0 18.2 18.2 - -
G397-025
(Size 3)
4
+4 0/+104
25.0 42.0 42.0
10
60.0 0.5
8 25.0 42.0 42.0 - -
12 21.8 33.1 33.1 - -
16 15.0 22.8 22.8 - -
G397-026
(Size 4)
4
+4 0/+104
30.0 48.0 48.0
10
72.0 0.5
8 26.3 4 8.1 48.1 - -
12 22.5 31.5 31.5 - -
16 16.1 22.5 22.5 - -
G397-035
(Size 4)
4
+4 0/+104
40.0 64.0 64.0
10
96.0 0.5
8 35.0 64.0 64.0 - -
12 30.0 42.0 42.0 - -
16 21.4 29.9 29.9 - -
1) At max. 70 % preload
2) Shutdown as per I²t characteristic
All data apply for motor cable length ≤10 m
Table B.6 Rated and peak current, Size 3 and Size 4 (liquid-cooled, 400VAC)
B.1.7 Size 3 and Size 4 (liquid-cooled, 460VAC)
Type
Power stage
switching
frequency
Ambient
temperature
Rated current
Peak current
1)
I
MAX
0Hz
I
1MAX
≥5Hz
t
1
2)
I
2MAX
≥5Hz
t
2
2)
[kHz] [°C] [A
eff
] [A
eff
] [A
eff
] [s] [A
eff
] [s]
G397-020
(Size 3)
4
+4 0/+104
20.0 33.6 33.6
10
48.0 0.5
8 17.4 29.2 29.2 - -
12 12.5 19.0 19.0 - -
16 9.1 13.8 13.8 - -
G397-025
(Size 3)
4
+4 0/+104
25.0 42.0 42.0
10
60.0 0.5
8 21.8 36.6 36.6 - -
12 15.6 23.7 23.7 - -
16 11. 4 17.3 17.3 - -
G397-026
(Size 4)
4
+4 0/+104
26.0 41.6 41.6
10
62.4 0.5
8 23.0 42.0 42.0 - -
12 17.7 24.8 24.8 - -
16 12.8 17.9 17.9 - -
G397-035
(Size 4)
4
+4 0/+104
33.7 53.9 53.9
10
80.9 0.5
8 30.6 55.9 55.9 - -
12 23.6 33.0 33.0 - -
16 17.0 23.8 23.8 - -
1) At max. 70 % preload
2) Shutdown as per I²t characteristic
All data apply for motor cable length ≤10 m
Table B.7 Rated and peak current, Size 3 and Size 4 (liquid-cooled, 460VAC)
