NOTE: Arrange devices with different drive power in descending order of
power output (e.g. viewed from the left Size 4 - Size 3 - Size 2 - Size 1). This
minimizes the mutual thermal influence. The supply unit must always be
arranged on the side of the most powerful DC-AC servo drive.
When side by side mounting MSD Servo Drives together with other devices,
you must make sure that the device do not affect one another thermally.
H3
A
B
A1
C1
A2
S
D1
T
T1
H1 H
D
D
H2
C
Fig. 2.3 Dimensional drawing, liquid-cooled housing
E
G
F
F
Fig. 2.4 Mounting clearance, liquid-cooled housing
