Ԟ Selecting the sheet (paper) thickness
٤ LCD display for selecting the sheet (paper) thickness
LED display Power LED: ON, READY : OFF, ERROR: OFF
No. Display information Display Changes
Ԙ Shows that this is for selecting sheet (paper) thickness INOP (Fixed screen)
ԙ Shows the sheet (paper) thickness selection state. Pressing
the UP/DOWN switch changes this display.
Pressing the UP/DOWN switch allows 3 choices for paper
thickness as follows:
U: Thin F: Regular A: Thick
OK
Ԛ An "H" is shown when the displayed setting has been saved. A
blank space is shown when in the setting change state.
OK Shows "H" or
blank display.
Note 1: The only location settable by the user is ԙ .
○ Sheet (paper) thickness switches
Switches Description
UP - DOWN UUse for selecting the sheet (paper) thickness. Enabled by ԙ .
ENTER Use to enter the display information. (After entering, an "H" ap-
pears in (3)).
CLEAR Shows the default (reset value).
MENU Setting Entry mode; Shifts to Menu screen 1.
Note 1: The data changes are not entered (stored) if the Menu switch is pressed before the
Enter switch was pressed.
Note 2: If an error such as Cover-Open was detected before pressing the Enter switch then
after eliminating the error, operation shifts to Standby mode without storing any
changes.
٤ Guide to selecting paper thickness
Use the following table as a general guide for selecting the paper thickness. The following
settings are only a general guide so if paper feed errors occur change the setting that is 1 level
thicker.
Sheet Thickness
Setting
Cutting Thickness Paper type & Weight (kg) Guide
A (thick) approx. 0.23 to 0.40 Artist papers (788x1091mm, 200 to
280kg)
F (regular) approx. 0.18 to 0.22mm Fine paper -- Craft type, Coated paper,
Artist papers (788x1091mm, 110 to
200kg)
U (thin) approx. 0.12 to 0.17mm Fine paper - Craft type, Coated paper
(788x1091mm, 90kg)
To Next Page
