1 Place the SUC on a flat surface.
2 Insert the connector of the power supply into the port
on the side of the SUC.
3 Plug the AC adapter into a power outlet.
4 Insert the radio into the SUC with the front of the
radio facing the LED of the SUC. Ensure the radio is
securely inserted all the way into the charger.
NOTICE:
For more information, see LED Indicator of
Chargers on page 24 and Operational
Safety Guidelines on page 9.
The charger LED flashes a few times to indicate the
current battery capacity when the radio is inserted in
the tray rails. The light on the charger is red to
indicate that the battery is charging and turns green
indicates that the battery is fully charged.
Charging a Stand-Alone Battery
Insert the battery into the charging pocket with the
front of the battery facing the LED of the Single Unit
Charger (SUC).
The charger LED flashes a few times to indicate the
current battery capacity when the radio is inserted in
the tray rails. The light on the charger is red to
indicate that the battery is charging and turns green
indicates the battery is fully charged.
English
22
