Motorola solutions DTR600 User Manual

1 2 3 4
5
Figure 5: Multi-Unit Charger
Label Item
1 Pocket 1
2 Pocket 2
3 Pocket 4
4 Pocket 5
5 "CLONE" symbol
1 Turn on the Target radio and place it into one of the
MUC Target Pockets.
2 Power the Source radio by performing the following
actions:
a Press the Menu/OK → Advanced → Cloning →
Radio Cloning
b Put the radio inside the MUC pocket.
c Press the Menu/OK button.
The display shows Cloning....
If successful:
• The display shows Cloned Successfully.
If unsuccessful:
• The display shows Cloning Failed.
NOTICE:
After completing the cloning process, user
can replace the Slave Radio with another
Slave Radio and by pressing the Menu/OK
button on the Master radio to clone on
second Slave Radio.
English
46

Motorola solutions DTR600 Specifications

General

Brand	Motorola solutions
Model	DTR600
Category	Two-Way Radio
Language	English
