Page #187 background image
Mixed I/O Module
14-6
Connection Charts
Mixed I/O
Pin Function Pin Function
1 DI1 21 COM1
2 DI2 22 NC1
3 DI3 23 NO2
4 DI4 24 COM2
5 DI5 25 NC2
6 DI6 26 NO3
7 DI7 27 COM3
8 DI8 28 NC3
9 DI9 29 NO4
10 DI10 30 COM4
11 DI11 31 NC4
12 DI12 32 AI1+
13 DI13 33 AI1-
14 DI14 34 AI2+
15 DI15 35 AI2-
16 DI16 36 AI3+
17 24V+ 37 AI3-
18 COM1 38 AI4+
19 PGND1 39 AI4-
20 NO1 40 PGND
