Digital Output Relay 120/230V Module
10-10
DO Relay 120/230V Module Specifications
Total Number of Outputs 12 EE relay outputs
12 ML relay outputs
Output Arrangement 12 x 1 Form A
Contact Power Ratings 3A @ 250 V AC, 3A @ 30 V DC, or 0.20A @ 125 V DC (resistive load)
Minimum Contact Load
Current
10.0 mA @+5.00 V DC
Maximum Switching Current 3.00 A
Relay Back Indication Contact position - hardware back indication
DO Frequency Max. 10 Hz (resistive load)
Diagnostic LEDs LED per each output status, module error LED
User Connection 3 Terminal Blocks (5.00mm pitch), Maximum 14 AWG
Cable and TB Holder 30-wire cable braid with Terminal Block holder connector, 20 AWG
Fail State Configurable relay state on CPU fail: On, Off or ‘last value’
All Relays Disable/Enable Selectable per module, controlled from the power supply
Module Replacement Hot swap replacement – module extraction/insertion under voltage
Output Isolation Between output and module logic 2.5 kV per IEC60255-5
Insulation Insulation resistance 100 MΩ @ 500 V DC per IEC60255-5,
Insulation impulse 5 kV per IEC60255-5
Operating Voltage 10.8-16 V DC and 3.3 V DC ±10% (from the motherboard connector)
Power Consumption Refer to Appendix D: ACE3600 Maximum Power Ratings.
Dimensions 37 mm W x 225 mm H x 180 mm D (1.5" W x 8.7" H x 7.1" D)
Weight approx. 0.423 kg (0.90 lbs)
Specifications subject to change without notice.
