Analog Output Module
13-11
AO Module Specifications
Total Number of Outputs 4 AO current (0-20 mA) or voltage (0-10 V)
Output Arrangement Isolated floating channels, each channel can be connected as
0-20 mA or 0-10 V DC voltage
D to A Resolution 14 bit
Output Accuracy ±0.05% full scale @ 25ºC
Temperature Stability 25 PPM/ºC
Internal Settling Time Max. 1.0 msec
Output Load Voltage: > 1.0 kΩ, < 1.0 µf
Current:
< 750 Ω (internal power source)
Crosstalk Rejection Better than 50 dB between any pair of outputs
Interference Suppression Common mode rejection > 60 dB
Output Protection Voltage output: short circuit current, max. 30 mA
Current output: No-load voltage max. 22 V DC
Diagnostic LEDs Module error LED, Voltage mode LED, Current mode LED,
Calibration LED per channel
User Connection 2 Terminal Blocks (3.5mm pitch), Maximum 18 AWG
Cable and TB Holder 20-wire cable braid with Terminal Block holder connector, 26 AWG
Module Replacement Hot swap replacement– module extraction/insertion under voltage
Isolation 1.5 kV between output and module logic
Insulation Insulation resistance 100 MΩ @ 500 V DC, per IEC60255-5
Operating Voltage 10.8-16 V DC and 3.3 V DC (from the motherboard connector)
Power Consumption Refer to Appendix D: ACE3600 Maximum Power Ratings.
Dimensions 37 mm W x 225 mm H x 180 mm D, (1.5" W x 8.7" H x 7.1" D)
Weight Approx. 0.29 Kg (0.64 Lb)
Specifications subject to change without notice.
