ACE IP Gateway Module
20-12
ACE IP Gateway Module Specifications
Microprocessor Freescale – Power PC II MPC8270, 32-bit, extended communication capability,
DMA and floating point calculation support
Microprocessor
Clock
200 MHz
Memory Flash: 32 MB
SDRAM: 128 MB
Real-Time Clock Full calendar with leap year support (year, month, day, hours, minutes, seconds).
Time drift: max. 2.5 Seconds per day (when power is on)
RTC Retention 3 V Rechargeable lithium backup battery
Serial Port 1 Configurable RS232 or RS485 port:
- RS232: Asynch, Full Flow Control, up to 230.4 kb/s, GPS receiver interface
- RS485, multi-drop 2-Wire up to 230.4 kb/s
Serial Port 2 RS232, Asynch, Full Flow Control, up to 230.4 kb/s, GPS receiver interface
Plug-In Port 1 Supports the following plug-in ports:
- Radio Modem, DPSK 1.2 kb/s, FSK 1.2/1.8/2.4 kb/s, DFM 2.4/3.6/4.8 kb/s
- RS232, Sync/Asynch, Full Flow Control, up to 230.4 kb/s,
GPS receiver interface
- RS485, multi-drop 2-Wire up to 230.4 kb/s
- Ethernet 10/100 Mb/s
Plug-In Port 2 Supports the following plug-in ports:
- Radio Modem, DPSK 1.2 kb/s, FSK 1.2/1.8/2.4 kb/s,
DFM 2.4/3.6/4.8 kb/s
- RS232, Sync/Asynch, Full Flow Control, up to 230.4 kb/s,
GPS receiver interface
- RS485, multi-drop 2-Wire up to 230.4 kb/s
- Ethernet 10 Mb/s
USB Host Port 1, 2
Type A host full speed 12 Mbs ports (HU1 on left and HU2 on right) for MDLC
over IP communication via the MotoTrbo digital mode radio system
USB Device Port 1 USB Device port
LEDs Display 4 CPU diagnostic LEDs and Port status LEDs
Power Consumption Refer to Appendix D: ACE3600 Maximum Power Ratings.
Operating Voltage 10.8-16 V DC (from the motherboard connector)
Dimensions 56 mm W x 225 mm H x 180 mm D (2.2" W x 8.7" H x 7.1" D)
Weight Approx. 0.38 Kg (0.84 Lb)
Specifications subject to change without notice.
