A-1
APPENDIX A: GENERAL SPECIFICATIONS
Specifications
The specifications below are for the RTU as a whole. For the individual technical and
performance specifications of each module in the RTU, see the specific module chapter.
Table A-1 ACE3600 Specifications
General
Frames No I/O slots - PS and CPU modules only, wall mount,
Dimensions (WxHxD): 117 x 209 x 198* mm (4.61" x 5.30" x 7.80"*),
Weight: 0.95 Kg (2.1 lb)
2 I/O slots - PS, CPU and 2 I/O modules, wall mount,
Dimensions (WxHxD): 194 x 244 x 198* mm (7.64" x 9.61" x 7.80"*),
Weight: approx. 1.6 Kg (3.56 lb)
3 I/O slots - PS, CPU and 3 I/O modules, wall mount,
Dimensions (WxHxD): 234 x 244 x 198* mm (9.21" x 9.61" x 7.80"*),
Weight: approx. 1.9 Kg (4.19 lb)
5 I/O slots - PS, CPU and 5 I/O modules, wall mount,
Dimensions (WxHxD): 314 x 244 x 198* mm (12.36" x 9.61" x 7.80"*),
Weight: approx. 2.4 Kg (5.3 lb)
7 I/O slots - PS, CPU and 7 I/O modules; wall mount,
Dimensions (WxHxD): 391 x 244 x 198* mm (15.39" x 9.61" x 7.80"*),
Weight: 3.0 Kg (6.6 lb)
8 I/O slots - PS, CPU and 8 I/O modules, wall mount OR 19" rack
Dimensions (WxHxD): 435 x 244 x 198* mm (17" x 9.61" x 7.80"*),
Weight: approx. 3.3 Kg (7.3 lb)
Redundant CPU and power supply frame - Dual PS, Dual CPU, and 4 I/O
modules; wall mount OR 19" rack,
Dimensions (WxHxD): 391 x 244 x 198* mm (15.39" x 9.61" x 7.80"*),
Weight: 3.0 Kg (6.6 lb)
* Depth including Module panel
