Icon Description
On
AES secure operation.
Off
Clear operation.
Blinking
Receiving an encrypted voice call.
On
Feature is enabled and GPS signal is available.
Blinking
Feature is enabled, but no GPS signal is available.
User Login Indicator (IP Packet Data)
On
User is associated with the radio.
Blinking
Device registration or user registration with the server failed
due to an invalid username or pin.
Inverted
User successfully logged in to the secured IP Packet Data.
Data activity is present.
Bluetooth is on and ready for Bluetooth connection.
The Wireless-Pair device is on.
The Wireless-Pair device is connected.
Steady – LTE system is available and connected.
Blinking – ARS user login failed while in LTE system.
The radio is receiving LTE signal.
The radio is transmitting LTE signal.
The radio is receiving and transmitting LTE signal.
MN006147A01-AE
Chapter 4: Status Indicators
29
