6816985H01-F
6.4-18
700/800 MHz Troubl
eshooting Charts:
700/800 MHz Frequency Generation Unit Troubleshooting Chart
6.4.19
700/800 MHz Frequency Genera
tion Unit T
roubleshooting Chart
MAEPF-27346-O
FGU NoLO
Injection/TX
Unlock
For RX check C263,
L258, C267, C261,
R293 and R294 for
continuity
.
For TX check C278,
L274, C276, C279,
R273, R274 and R275
Change U250
Replace Y200
and/or C214
Check
U201 circuitry
Replace
U202
Fix/replace
U201
Do a continuity
check and refer to
DC switch chart
Replace
U202
Do a continuity
check and refer to
DC switch chart
Replace
suspected
component
Is Vdc at
D251&D252(RX VCO)
D270(Tx VCO)
0.4<Vdc<12?
Is Vdc at
R259,
High for Tx,
Low for Rx mode
No
T
ake a continuity
check of traces
to U201
No
No
No
No
No
No
No
No
No
No
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Is Vdc
at C218 3V?
and C21
1
5V?
Is there
a voltage reading
at R204, R205, C206,
C207 directed
to U202?
Is Vdc
at Y200 pin 4
3V?
Do you
see 16.8MHz at
pin 3 of Y200 and C214
connection to Xtal
K9 pin of
U202?
Do
you see
16.8MHz at
C245?
Do
you see
~1
1.5 Vdc at pin 2
of D202?
Replace
U202
Ye
s
Is
3Vdc at
pin 4 of
D201?
Check components
D201, D202, C206,
C207, C208
and C209
For TX only pin 3 of Q216 (TX)
255
257
